Acoustic Writing Boards from Yayin New Materials
As a Acoustic writing boards Manufacturers manufacturer, we match product configuration to the application, operating limits, interfaces and acceptance criteria defined for each project.
As a China-based Acoustic writing boards manufacturer, Yayin New Materials Jiangsu Co., Ltd. combines the functionality of a whiteboard with high-performance sound absorption. Our boards are engineered for meeting rooms, open offices, classrooms, and collaborative spaces where both writable surfaces and noise control are required. We produce them using our carbon-neutral polyester fiber panels, which are recyclable, antibacterial, and meet international flame-retardant standards.
Our range includes two main configurations: fabric-wrapped boards with a magnetic tempered glass surface and polyester fiber boards designed for partition integration. Both types are available in custom sizes, colors, and edge finishes to match your interior design and acoustic plan.
Key performance: NRC 0.85, ASTM E84 Class A, EN13501-1 Class B, UL723-2018 Class A, formaldehyde E0 level. Certified ISO9001 and ISO14001.
Product Range and Application Fit
We supply two board types, each suited to different installation contexts:
- Fabric-wrapped boards with magnetic tempered glass: Ideal for meeting rooms and training areas. The glass surface provides a smooth writing experience and allows magnetic attachments. The fabric-wrapped edges and backing contribute to sound absorption.
- Polyester fiber boards for partition integration: Designed to be mounted on or integrated with acoustic office partitions. These boards offer a writable surface while maintaining the acoustic performance of the partition system.
Both types are manufactured with our needle-punched nonwoven polyester fiber, which provides consistent acoustic absorption across the entire board area. We can also produce boards with a printed or colored surface to align with your branding or décor.
Technical Specifications and Compliance
| Parameter |
Value |
| Noise Reduction Coefficient (NRC) |
0.85 |
| Flame Retardant |
ASTM E84 Class A, EN13501-1 Class B, UL723-2018 Class A |
| Formaldehyde Emission |
E0 level (national standard) |
| Material |
Carbon-neutral polyester fiber, recyclable |
| Surface Options |
Magnetic tempered glass, polyester fiber, custom printed |
| Certifications |
ISO9001, ISO14001 |
Engineering and Customization
We understand that each project has unique dimensions and acoustic targets. Our engineering team works with you to specify the core thickness, surface type, edge profile, and mounting method. For partition-integrated boards, we coordinate with the partition design to ensure a flush fit and consistent acoustic performance.
We offer customization in:
- Size (width, height, thickness)
- Surface color and finish
- Edge wrapping (fabric, PVC, or aluminum)
- Accessories (trays, markers, magnets)
- Printed graphics or logos
Quality Assurance and Testing
Every board is produced in our ISO9001-certified facilities. We conduct in-process checks on density, thickness, and surface quality. Final products are tested for acoustic performance (NRC), flame retardancy, and formaldehyde emission in accordance with the standards listed above. We provide test reports and certificates upon request.
Installation and Maintenance
Boards can be surface-mounted on walls or integrated into partition systems. We supply mounting hardware and installation instructions. For glass-surface boards, use standard whiteboard markers and clean with a soft cloth. The polyester fiber surface is durable and easy to maintain; vacuum or wipe with a damp cloth as needed.
Information We Use to Configure Your Solution
To prepare a precise quotation and technical proposal, we need the following project details:
- Application (meeting room, classroom, open office, etc.)
- Required dimensions and quantity
- Surface preference (glass, polyester, printed)
- Mounting method (wall, partition, freestanding)
- Acoustic target (desired NRC or reverberation time)
- Color and finish requirements
- Any special certifications or documentation needed
Share these details with our team, and we will respond with a tailored configuration, sample options, and lead time.
Frequently Asked Questions
Can I use standard whiteboard markers on the glass surface?
Yes, our magnetic tempered glass surface is designed for dry-erase markers. It wipes clean easily and resists ghosting.
Are the boards suitable for high-humidity environments?
Our polyester fiber core is moisture-resistant and does not support mold growth. For humid areas, we recommend the glass-surface version to protect the writing surface.
Do you provide samples before bulk order?
Yes, we offer free samples. Standard production lead time is 7–10 working days after order confirmation.
Can the boards be integrated with our existing partition system?
Yes, we can design boards to fit specific partition frames. Provide us with the partition dimensions and mounting details, and we will engineer a compatible solution.
What flame-retardant standards do your boards meet?
Our boards meet ASTM E84 Class A, EN13501-1 Class B, and UL723-2018 Class A. Test reports are available on request.
